TORQUE WRENCH | 25 MM (1") | 300 - 1500 NM (2863)

suitable for torque tightening of screwed connections with right-hand thread
integrated reversible ratchet with narrow head shape
ratchet mechanism, reversible
easy locking and unlocking on the handle
lasered line scale with fine adjustment for the respective setting value
optimally designed steel handle for easy setting of the desired torque value, as well as a secure grip of the tool handle
clearly audible release
fine scale: 10 Nm
trigger clockwise: yes
trigger counter-clockwise: no
Technical data
Drive profile size, metric25 mm
Drive profile size, inch1 "
Output profileExternal square
Length1795 mm
Width60 mm
Gross weight13000 g
Max. torque1500 Nm
Min. torque300 Nm
No. of teeth in ratchet head24
Release accuracy+/- 3 %
