PNEUMATIC MINI DIE GRINDER /REAR EXHAUST (YT-0965)

Brand
Yato
Symbol
YT-0965
Series
GRG
Set contents
pneumatic grinder, hose connector, tool holder wrench x2
Rotational speed
20000 min1
Housing material
aluminum
Tool holder size
3 mm, 1/4" (6.3 mm)
Weight
0.57kg
Sound pressure
100.7 2.4 dB(A)
Acoustic power
106.2 3.7 dB(A)
Vibrations
2.83 0.93 m/s2
Maximum equipment diameter
40mm
Operating mode
intermittent S2 5 min
Required air flow
160 l/min
Max. working pressure
0.7 MPa
Air connection diameter (PT)
standard
Recommended working pressure
0.62 MPa
Inner diameter of the air supply hose
3/8" (9.5 mm)

Pneumatic grinder, straight



A pneumatic grinder is a tool powered by a stream of compressed air at appropriate pressure. Using end mills, it is possible to grind various materials.



Package contents

The grinder is equipped with a connector that allows it to be connected to the pneumatic system. The equipment also includes wrenches for attaching additional equipment to the holder



Parameters

pressure [bar]: 6.2
min/max revolutions: 20000
quick connector size [inch]: 1/4"
spindle size [mm]: 3, 6
capacity [l/min]: 160
