ENGINE TIMING TOOL SET | FOR ROVER, PEUGEOT, FORD, VOLVO 2.0, 2.2L D (8529)

Product description

This engine timing tool kit is designed for inspection and adjustment of engine timing on a range of 2.0L and 2.2L diesel engines used in various Peugeot, Citroen, Land Rover, Volvo, and Ford vehicles. The kit provides the necessary locking tools to secure the camshaft, crankshaft, and flywheel during timing belt replacement or other engine timing procedures. It is suitable for use with engines such as the Peugeot DW10UTED4, DW10BTED4, DW12BTED4, Citroen DW10BTED4, Land Rover 224DT, Volvo D420T 2.0D, and several Ford engine codes including QXBA, QXWA, QXBB, Q4BA, QXWB, AZBA, AZBC, and AZWA.

This tool set is typically used during timing belt changes, timing chain service, or when performing repairs that require precise alignment of the engine’s internal components. By locking the relevant engine parts in place, it helps prevent misalignment and potential engine damage during maintenance.

Compatible vehicles

• Peugeot:
• 807 (2005-2011)
• 407 (2005-2011)
• 607 (2005-2009)
• Engines: DW10UTED4 (RHK), DW10BTED4 (RHR), DW12BTED4 (4HS, 4HP, 4HT, 4HR)
• Citroen:
• C4 (2004-2010)
• C5 II (2004-2010)
• Engine: DW10BTED4 (RHR)
• Land Rover:
• Freelander (2006-2010)
• Engine: DW12BTED4, 224DT
• Volvo:
• S40 (2003-2010)
• V50 (2006-2010)
• C70 (2006-2010)
• S80 (2007-2010)
• C30 (2006-2010)
• V70 (2007-2010)
• Engine: D420T 2.0D
• Ford:
• S Max 2.2 (2008-2010)
• Galaxy 2.2 (2008-2010)
• Mondeo 2.2, 2.0 (2007-2010)
• Engine codes: QXBA (2.2), QXWA (2.0), QXBB (2.0), Q4BA (2.2), QXWB (2.0), AZBA (2.0), AZBC (2.0), AZWA (2.0)

Kit contents

• Camshaft locking tool (OEM PSA 0188.M / Ford 303-735 / Volvo 999-7122)
• Crankshaft locking tool (OEM PSA 0188.X / Ford 303-1059 / Volvo 999-7121)
• Flywheel locking tool (OEM PSA 0188.F / Ford 303-393A, 303-393-01 / Volvo 999-7119, 999-7120)

Technical specifications

OEM reference table:

• Citroen: OEM 10188M, 0188X, 0188F
• Peugeot: OEM 20188M, 0188X, 0188F
• Ford: OEM 3303-1277, 303-1270, 303-1059, 303-1272, 303-735, 303-393A, 303-393-01
• Volvo: OEM 49997119, 9997120, 9997121, 9997122
