BELT DRIVEN OIL COMPRESSOR 400V 200L (YT-23321)

Brand
Yato
Entity responsible for this product in the EU
TOYA S.A.More
Power
3 HP
2200 W
Max. pressure
1 / 10 / 145 MPa/bar/PSI
Efficiency
360 l/min
Revolutions
1100 min1
Voltage
400 V a.c.
Frequency
50 Hz
Short-circuit current
27 A
Load current
4.5 A
Tank capacity
200 l
Number of cylinders in the engine
2
Wheels
yes
Number of wheels
4
Manometer
yes
Electrical insulation class
I
Protection class
IP32
Sound pressure
75.1 2.11 dB(A)
Sound power
95.1 2.11 dB(A)
Weight
125 kg
Set contents
compressor, quick connector x2
Symbol
YT-23321

Two-cylinder oil compressor with two connections and pressure regulation. Used to drive compressed air devices, blow drilling and clean surfaces in industry, workshops, agriculture, and on construction sites.

power: 2200 W (3 HP)
engine speed: 1100 rpm
capacity: 360 l/min
max. pressure: 1 MPa/10 bar
tank capacity: 200 l
pressure gauge
protection class: IP32
electrical insulation class I
4 wheels
weight: 125 kg
2 quick connectors included

Use warnings:

Note! Before first use, top up the oil and replace the transport plug with the supplied oil plug.
