AUTO-DARKENING WELD. HELMET TRUE COLOR (YT-73930)

YATO
Model: ASTRO TRUE COLOR AUTO-DARKENING WELDING HELMET
YT-73930

Series: GRD
Application: for welding
Operating temperature range: -5 ~ +55 C
Storage temperature: -20 ~ +70 C
Power source: solar cell, battery, USB
Battery type: 1x3.6V; LIR2450
Functions: grinding, cutting, welding
Automatic on/off: Yes
Low battery indicator: Yes
Standard: EN 175:1997, EN 379:2003 + A1:2009
Welding method: MMA, MIG, MAG, TIG
Filter size: 134x124mm
Protective glass size: 270x125 mm
Viewing area: 100x68mm
Filter type: auto-darkening TRUE COLOR
Dark state: 5-8, 9-13 DIN
Light state: 4 DIN
Reaction time: 1/25000 s
Lightening time: 0.2-1 s
Number of levels: 4
UV/IR resistance: yes, DIN 16
Optical properties: 1/1/1/1
Adjustment: yes, external
Filter test: Yes
4-point harness: Yes
Helmet material: PA6
Fast material: P.C
Delay adjustment: Yes, external

Astro welding helmet with a true color auto-darkening filter, allowing observation of the welding area in realistic colors. Certified welding filter in the highest optical class 1/1/1/1. The filter provides a large viewing area of 100x68 mm and protection against UV/IR radiation at DIN 16 level. The filter is protected against splinters by a durable polycarbonate glass. Four arc sensors and precise electronic devices detect electric arc from TIG with intensity of just 5A. The filter is powered by a solar cell and a LIR2450 battery, which can be charged via the built-in USB-C socket.

Adjustments for the helmet's darkening level, sensitivity to the light source intensity, and the time for maintaining the dark state after welding. A button on the outer casing disables the darkening function. The helmet can then be used as personal protective equipment, e.g., against splinters from metal cutting or grinding. A four-point harness, sweatband, and a system for adjusting size and working angle allow customizing the helmet's position according to individual requirements and work comfort.

The filters have a TEST button, allowing to check the operation of the auto-darkening function. Regular filter checks before work will help protect the operator's eyes and health.

Filter type: automatic darkening, true color
Optical properties: 1 / 1 / 1 / 1
Viewing area: 100x68 mm
Filter size: 134x124 mm
Reaction time: 1/25000 s
Lightening time: 0.2-1 s
Number of sensors: 4
Dark state: 5-8|9-13 DIN
Light state: 4 DIN
Filter test
Sensitivity adjustment
Darkening adjustment
Power source: solar cell, LIR2450 battery, USB
Standard: EN 175:1997|EN 379:2003 + A1:2009
UV/IR resistance: yes, DIN 16
Operating temperature range: -5 ~ +55 C
